Features

Selectable Languages

Chinese, English, Japanese, French, German, Spanish, Portuguese and Russian;

Fonts

Default font is Arial, allows users to load the fonts they need;

Barcodes

UPCA, UPCE, EAN13, EAN8, INT25, CODE39, CODE128, ENA  128, PDF417, DATAMATRIX, QR;
 (Allows user to add the barcode)

Date format

Variety of date modes available (Production Date, Use by Date, Expiration Date, etc);

Counters

Flexible setting for serial number, Lot-Box code counters;

Print Speed

Print speed can be set, auto-measuring or using external synchronizer;

Multi-Management

Multi-level password protection (Operator, Technician and Administrator);

PC Software's Database

MS Excel,  MS Access,  SQL2000,  SQL 2005,  SQL2008

 Device's Database suport

Provide standard port of  RS-232, Ethernet, easy to integrate for customers

Technical Parameters

Technology

HP TIJ2.5, utilizing HP driver board for reliability of printing quality;

Dimensions

(H*W*D): 142*65*98mm/ 5.6*2.6*3.9inch; (Anti-shock cover is not included)

Power Supply

AC 90V-240V/50-60HZ, 60W; (Dedicated AC adaptor)

Printable Heights

1~12.7mm

Printing speed

0-60m/min (300 DPI);

Resolution

50~600DPI

Port

1) Ethernet: 100Mb/s, Synchronized control of multiple devices via PC;
  2) USB2.0: Support U-Disk;
  3) DB15: For external devices like photocell, synchronizer or alarm kit connection;

Printing Objects

Barcodes, Character, Numeric, Logos, Date/Time, Expiry Date, Shift Code, Counter, Lot-Box Code;

Interface

1) 5inch 800*480 color LCD touch screen;
  2) 90 degree flip-screen design

Ink management

1) Automatically recognize the ink types, and identify the optimum printing parameters;
  2) Guarantee of using genuine original HP ink;
  3) Automatic measuring system for the usage of the ink;

Mounting

Standard side, downside and anti-shock printing bracket;

Product Certification

CE、FCC

Environment

1) Working Environment: -10°-- +55°C;  10%-85%RH;
  2) Storage Environment:  -25°-- +80°C;  10%-90%RH;

Features

Selectable Languages

Chinese, English, Japanese, French, German, Spanish, Portuguese and Russian;

Fonts

Default font is Arial, allows users to load the fonts they need;

Barcodes

UPCA, UPCE, EAN13, EAN8, INT25, CODE39, CODE128, ENA  128, PDF417, DATAMATRIX, QR;

 (Allows user to add the barcode)

Date format

Variety of date modes available (Production Date, Use by Date, Expiration Date, etc);

Counters

Flexible setting for serial number, Lot-Box code counters;

Print Speed

Print speed can be set, auto-measuring or using external synchronizer;

Multi-Management

Multi-level password protection (Operator, Technician and Administrator);

PC Software's Database

MS Excel,  MS Access,  SQL2000,  SQL 2005,  SQL2008

 Device's Database suport

Provide standard port of  RS-232, Ethernet, easy to integrate for customers

Technical Parameters

Technology

HP TIJ2.5, utilizing HP driver board for reliability of printing quality;

Dimensions

(H*W*D): 170*143*106mm/ 6.7*5.6*4.17inch;

Power Supply

AC 90V-240V/50-60HZ, 60W; (Dedicated AC adaptor)

Distance and

Printhead Stretch

Two deflectors available according to different request;

Printhead stretch between 0-12mm according to different curves;

Printing speed

0-60m/min (300 DPI);

Resolution

50~600DPI

Port

1) Ethernet: 100Mb/s, Synchronized control of multiple devices via PC;
2) USB2.0: Support U-Disk;
3) DB15: For external devices like photocell, synchronizer or alarm kit connection;

Printing Objects

Barcodes, Character, Numeric, Logos, Date/Time, Expiry Date, Shift Code, Counter, Lot-Box Code;

Interface

1) 5inch 800*480 color LCD touch screen;
2) 90 degree flip-screen design

Ink management

1) Automatically recognize the ink types, and identify the optimum printing parameters;
2) Guarantee of using genuine original HP ink;
3) Automatic measuring system for the usage of the ink;

Mounting

Standard side, downside and anti-shock printing bracket;

Product Certification

CE、FCC

Environment

1) Working Environment: -10°-- +55°C;  10%-85%RH;
2) Storage Environment:  -25°-- +80°C;  10%-90%RH;

Features

Selectable Languages

Chinese, English, Japanese, French, German, Spanish, Portuguese and Russian;

Fonts

Default font is Arial, allows users to load the fonts they need;

Barcodes

UPCA, UPCE, EAN13, EAN8, INT25, CODE39, CODE128, ENA  128, PDF417, DATAMATRIX, QR;

 (Allows user to add the barcode)

Date format

Variety of date modes available (Production Date, Use by Date, Expiration Date, etc);

Device's Database suport

Provide standard port of  RS-232, Ethernet, easy to integrate for customers

PC Software's Database

MS Excel,  MS Access,  SQL2000,  SQL 2005,  SQL2008

Technical Parameters

Technology

HP TIJ2.5;

Dimensions

Controller(H*W*D): 210*135*37mm/8.3*5.3*1.46inch
One print head(H*W*D): 126*100*31mm/4.9*3.9*1.2inch
(Anti-shock cover is not included);

Power Supply

AC 90V-240V/50-60HZ, 90W (Dedicated AC);

Printable Heights

1~12.7mm (one print head)
1~25.4mm (two print heads)

Printing speed

0~60m/min（300DPI）

0~30m/min（600DPI）

Resolution

50~600DPI

Port

1) Ethernet: 100Mb/s, Synchronized control of multiple devices via PC;
2) USB2.0: Support U-Disk;
3) DB15: For external devices like photocell, synchronizer or alarm kit connection;

Printing Objects

Barcodes, Character, Numeric, Logos, Date/Time, Expiry Date, Shift Code, Counter, Lot-Box Code;

Interface

1) 7 inch 800 *480 color LCD touch screen;
2) With touch screen interface operation, easy to use;
3) Printer can work separately without PC software;

Ink management

1) Automatically recognize the ink types, and identify the optimum printing parameters;
2) Guarantee of using genuine original HP ink;
3) Automatic measuring system for the usage of the ink;

Mounting

Standard side and downside printing assembly, customers can fix it flexibly;

Product Certification

CE、FCC

Environment

1) Working Environment: -10°-- +55°C;  10%-85%RH;
2) Storage Environment:  -25°-- +80°C;  10%-90%RH;

Features

Selectable Languages

Chinese, English, Japanese, French, German, Spanish, Portuguese and Russian;

Fonts

Default font is Arial, allows users to load the fonts they need;

Barcodes

UPCA, UPCE, EAN13, EAN8, INT25, CODE39, CODE128, ENA  128, PDF417, DATAMATRIX, QR;

 (Allows user to add the barcode)

Date format

Variety of date modes available (Production Date, Use by Date, Expiration Date, etc);

Device's Database suport

Provide standard port of  RS-232, Ethernet, easy to integrate for customers

PC Software's Database

MS Excel,  MS Access,  SQL2000,  SQL 2005,  SQL2008

Technical Parameters

Technology

HP TIJ2.5;

Dimensions

Controller(H*W*D): 210*135*37mm/8.3*5.3*1.46inch
Print head(H*W*D): 142*133*55mm/5.6*5.2*2.15inch
(Including the spring mechanism)

Power Supply

AC 90V-240V/50-60HZ, 90W (Dedicated AC);

Printable Heights

1~12.7mm

Printing speed

0~60m/min（300DPI）

0~30m/min（600DPI）

Resolution

50~600DPI

Port

1) Ethernet: 100Mb/s, Synchronized control of multiple devices via PC;
2) USB2.0: Support U-Disk;
3) DB15: For external devices like photocell, synchronizer or alarm kit connection;

Printing Objects

Barcodes, Character, Numeric, Logos, Date/Time, Expiry Date, Shift Code, Counter, Lot-Box Code;

Interface

1) 7 inch 800 *480 color LCD touch screen;
2) With touch screen interface operation, easy to use;
3) Printer can work separately without PC software;

Ink management

1) Automatically recognize the ink types, and identify the optimum printing parameters;
2) Guarantee of using genuine original HP ink;
3) Automatic measuring system for the usage of the ink;

Mounting

Standard side and downside printing assembly, customers can fix it flexibly;

Product Certification

CE、FCC

Environment

1) Working Environment: -10°-- +55°C;  10%-85%RH;
2) Storage Environment:  -25°-- +80°C;  10%-90%RH;
